Application:
The machine is applicable for pharmacy,food,light industry,daily chemical round PET bottle or glass bottle labeling.The label is self-adhesive.
GF-LW2 automatic round wine labeling machine can stick one label, two labels(front and back labels),when the bottle have one label already, the machine can stick another label on right where you want.
Feature:
1.Adopting Germany SIEMENS PLC control
2.Adopting easy operation large touch screen
3.Adopting Germany label sensor
4.Adopting Japan object sensor
5.All machines are made of SUS304 stainless steel and 6063 aluminum alloy
6.Labeling head can deflex ±20º to suit taper bottle
7.Can be equipped coding machine(optional)
8.Can be equipped bottle feeding table(optional)
9.Capacity:2000-15000BPH
| Standard Model |
GF-LW2 |
| Label width(max): |
130mm |
| Label length: |
10-300mm |
| Conveyer belt width: |
101.6mm |
| Diameter of bottle(max): |
Φ110mm |
| Outside diameter of label roll(max): |
Φ350mm |
| Inside diameter of label roll: |
Φ76mm |
| Labeling speed(max): |
50 bottles/min |
| Accuracy of labeling: |
±1mm |
| Overall size(L*W*H): |
2200*1200*1400mm
|
